Morelo
Empire Liner · Single DishDrawer — standard on the Grand Empire series, optional on all other models
Fisher & Paykel · Exclusive importer for motorhomes & boats in Europe
Full-size dishwashing.
In just 410 millimetres of installation height.
The DishDrawer™ brings a full-size premium built-in dishwasher into spaces that rule out conventional appliances — motorhome, yacht, tiny house. It opens like a kitchen drawer instead of folding down, saving the door swing that blocks the aisle in narrow layouts. After the meal the dishes go straight back into the drawer — order and cleanliness even in the tightest of spaces.
410 mm
Installation height, single unit
43 dB(A)
Operating noise
6
Place settings per drawer
230 V
Mains or inverter operation
In series production across European vehicle and yacht building
Concorde
Liner · Single DishDrawer — fitted across all models
Carthago
chic e-line, chic s-plus, liner-for-two · Single DishDrawer
Dembell
all models as standard
Hanse Yachts
575, 12 m yacht · Single & Double DishDrawer
Bavaria Yachts
R series, 10 m motorboat
The approach
We do not simply supply a dishwasher. We make a full kitchen possible where there was never room for one.
For development, engineering and product management: the DishDrawer™ opens like a kitchen drawer instead of folding down. As exclusive importer, coolHouse supplies appliances, spare parts and service from a single source since 2009 — backed by over 25 years of experience from the inventor of the dish drawer.
Interactive · Explore in 3D
The DishDrawer™ – from every angle
Rotate, zoom, open the drawer: assess integration, proportions and operation directly on the model – exactly as your end customers will experience the appliance later.
- Panel-ready front – accepts your own decor panel and blends seamlessly into the furniture line
- Compact installation dimensions for tight spaces in motorhome and yacht
- Loads from the top – ergonomic loading without bending, even in cramped spaces
- Fisher & Paykel series quality, built for continuous mobile use
Drag to rotate · Scroll to zoom
Applications
Built for installation spaces where every centimetre is accounted for.
Two core markets with series references — the same solution scales into every other segment with tight installation space.
Premium motorhomes
Motorhomes
Full dishwashing performance despite a compact floor plan — with no compromise on payload or living quality. In series production at Morelo, Concorde, Dembell and Carthago
Yacht and boat building
Yachts
Low weight, quiet operation and a loading principle that stays securely locked even in a swell. In series production on the Hanse Yacht 575 and in the Bavaria R series.
Technology
The specs your engineering team needs first.
Three configurations cover the vast majority of mobile applications. Full dimensioned drawings, CAD files and data sheets in the Design Kit.
Configurations and installation dimensions
| Model | Configuration | Dimensions H×W×D | Capacity | Typical application |
|---|---|---|---|---|
| DD60SHI9 | Single, Series 9 | 410 × 599 × 571 mm | 6 place settings | Motorhome, sailing yacht, tiny house |
| DD60SHTI9 | Single tall, Series 9 | 454 × 599 × 571 mm | 6 place settings, plates up to 310 mm | Liner class, motor yacht |
| DD60DHI9 | Double, Series 9 | 820–880 × 599 × 571 mm | 12 place settings, 2×6 | Large liner, yacht from 12 m |
All configurations are designed for a customer-supplied furniture front (panel-ready). Series 11 is available in the same installation spaces.
Operating values
| Feature | Value | Relevance for installation |
|---|---|---|
| Noise level | 43 dB(A) | Critical in just a few square metres of living space |
| Water consumption | 7.9 litres (per drawer and cycle) | Determines the fresh and waste water tank balance |
| Energy consumption | 61 kWh per 100 cycles | Basis for battery capacity and charging technology |
| Wash programmes | 6 + 3 modifiers | Fast and Extra Dry |
| Sanitize | Additional programme | Protection against viruses and bacteria |
| Operation | Knock-to-Pause | Knock to pause the wash cycle |
Enough for a first assessment?
CAD files, dimensioned drawings and model-specific data sheets are in the Design Kit — free of charge.
Interactive · Space Check
Does the DishDrawer™ fit your installation space?
Enter the niche height and width — the check instantly shows which configuration fits and how much clearance remains.
Result
Guide values based on the appliance dimensions. Binding installation drawings in the Design Kit.
Request the Design KitOn-board power & connection
The question that comes first in vehicle building.
The DishDrawer™ is a 230-volt appliance. In mobile use it runs on shore power or on an inverter fed from the on-board electrical system — both are proven in motorhome and yacht building.
When sizing the inverter, the inrush current of the heating phase is decisive alongside the rated power draw. We coordinate the sizing on a per-project basis with your electrical engineering team.
Supply voltage
220–240 V
Mains frequency
50 Hz
Current
10 A
Water pressure
100–1000 kPa
Water inlet
3/4″ BSP (20 mm)
Rec. inverter
1,000 watts
Inrush current
no inrush current
RELIABILITY
A series decision does not end with approval.
We support your project well beyond the start of production.
01
Service in the DACH region
A comprehensive network of more than 80 authorised service partners in Germany, Austria and Switzerland ensures that your customers receive fast, competent support even after delivery.
02
Spare parts supply across the entire service life
Motorhomes and yachts are built to last for many years. That is why we secure the spare parts supply long term – directly through coolHouse, with our own spare parts shop and Europe-wide shipping.
03
Supply capability for any volume
From small batches to industrial series production we deliver reliably in the volumes you need. High warehouse capacity and coordinated processes create planning certainty.
04
Supply concepts for your production
Whether short-notice individual orders or regular series call-offs – we align our deliveries flexibly with your production schedule.
05
Sample appliances before the series decision
Before approval we provide you with a sample appliance on special terms. This allows installation, connections and function to be validated under real conditions in the vehicle or on board.
06
One dedicated contact
The same contact person supports you throughout the entire project – with years of experience in the domestic appliance, motorhome and yacht sectors and an understanding of the requirements of your engineering and series production.
From enquiry to series production
A clear path — from first contact to the series product.
Five steps proven in vehicle and yacht building.
01
Contact
Request the Design Kit, first call to scope things out.
02
Assessment
Technical assessment in the context of your installation space and on-board power.
03
Sample unit
Real installation and validation in the vehicle or on board.
04
Pilot
Integration into a model series, coordination of front and connection.
05
Series
A permanent solution in the range, with ongoing support.
Free · for technical decision-makers
The OEM Design Kit.
Everything for your internal technical assessment in one package. After you submit, your dedicated contact gets in touch personally — no automated mailing list.
- — CAD files (DWG, DXF, Revit, SketchUp)
- — Dimensioned drawings and installation sketches
- — Technical data sheets per configuration
- — Consumption and noise figures
- — Installation and operating manuals
- — Detailed planning guide
Request the Design Kit
In under a minute — straight to your inbox.
Direct line
Let us talk about your project.
Installation space, on-board power, series goals — you speak directly with someone who knows the brand and vehicle building. Response within 2 business days.
Your contact
Kersten Hoppe
Phone
Mobile
coolHouse AG
Bahnhofstraße 10 · 83059 Kolbermoor
